IT6000D Hochleistungs-Gleichstromversorgung Baureihe

Bei IT6000D handelt es sich um eineprogrammierbare Gleichstromversorgung mit Einfachausgang. Das Gerät eignet sichzur Bereitstellung von stabilem Gleichstrom mit hoher Leistung im Labor bzw.bei Prüfautomatik. Mit der Autoranging-Funktionalität ist die Baureihe IT6000Din der Lage, im ganzen Leistungsbereich breitere Kombination aus Spannung undStrom bereit zu stellen. Somit kommt eine einzigartige Flexibilität zustande. DieBaureihe IT6000D ist umfangreich einsetzbar. Im Standalone-Betrieb ergibt sichein Leistungsbereich von 6 kW bis 144 kW. Der Strom beträgt maximal 2040 A unddie Spannung maximal 2250 V. Ferner stehen vieleStandard-Kommunikationsschnittstellen zur Verfügung, was die Testentwicklungvereinfacht und beschleunigt. Das kompakte 3U-Design spart bei der Rack-Montageviel Platz. Für noch höhere Ausgangsleistung können einfach mehrere Geräteparallel geschaltet werden. Somit kann Stromversorgung mit einer Gesamtleistungvon bis zu 2 MW zustande gebracht werden.





Finden Sie ein Produkt
Model
Voltage
Current
Power
Resolution
Accuracy
Interface
Size
IT6005D-80-150
80V
150A
5kW
0.001V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6015D-80-450
80V
450A
15kW
0.001V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6010D-80-300
80V
300A
10kW
0.001V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6030D-80-900
80V
900A
30kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
6U
inquiry
IT6045D-80-1350
80V
1350A
45kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6060D-80-1800
80V
1800A
60kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6090D-80-2040
80V
2040A
90kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6075D-80-2040
80V
2040A
75kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6120D-80-2040
80V
2040A
120kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6105D-80-2040
80V
2040A
105kW
0.001V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6006D-300-75
300V
75A
6kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6012D-300-150
300V
150A
12kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6036D-300-450
300V
450A
36kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
6U
inquiry
IT6018D-300-225
300V
225A
18kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6054D-300-675
300V
675A
54kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6090D-300-1125
300V
1125A
90kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6072D-300-900
300V
900A
72kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6108D-300-1350
300V
1350A
108kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6144D-300-1800
300V
1800A
144kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6126D-300-1575
300V
1575A
126kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6012D-500-80
500V
80A
12kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6006D-500-40
500V
40A
6kW
0.01V/0.001A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6036D-500-240
500V
240A
36kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
6U
inquiry
IT6018D-500-120
500V
120A
18kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6072D-500-480
500V
480A
72kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6054D-500-360
500V
360A
54kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6108D-500-720
500V
720A
108kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6090D-500-600
500V
600A
90kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6144D-500-960
500V
960A
144kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6126D-500-840
500V
840A
126kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6012D-800-50
800V
50A
12kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6006D-800-25
800V
25A
6kW
0.01V/0.001A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6018D-800-75
800V
75A
18kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6036D-800-150
800V
150A
36kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
6U
inquiry
IT6054D-800-225
800V
225A
54kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6090D-800-375
800V
375A
90kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6072D-800-300
800V
300A
72kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6126D-800-525
800V
525A
126kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6108D-800-450
800V
450A
108kW
0.01V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6144D-800-600
800V
600A
144kW
0.01V/0.1A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6036D-1500-80
1500V
80A
36kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
6U
inquiry
IT6018D-1500-40
1500V
40A
18kW
0.1V/0.001A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6072D-1500-160
1500V
160A
72kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6054D-1500-120
1500V
120A
54kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6090D-1500-200
1500V
200A
90kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6108D-1500-240
1500V
240A
108kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6126D-1500-280
1500V
280A
126kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6018D-2250-25
2250V
25A
18kW
0.1V/0.001A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
3U
inquiry
IT6144D-1500-320
1500V
320A
144kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6054D-2250-75
2250V
75A
54kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6036D-2250-50
2250V
50A
36kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
6U
inquiry
IT6090D-2250-125
2250V
125A
90kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6072D-2250-100
2250V
100A
72kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
15U
inquiry
IT6108D-2250-150
2250V
150A
108kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6126D-2250-175
2250V
175A
126kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
IT6144D-2250-200
2250V
200A
144kW
0.1V/0.01A
≤0.02%+0.02%FS/≤0.1%+0.1%FS
USB/CAN/LAN/digital IO interface, optional GPIB/Analog&RS232 interfaces
27U
inquiry
Show all
* The above specifications are subject to change without prior notice.
Produktmerkmale

 Spannung im Standalone-Betrieb: 80 Vbis 2250 V, Strom im Standalone-Betrieb: 30 A bis 2040 A, Leistung imStandalone-Betrieb: 6 kW bis 144 kW

 Mit Master/Slave-Parallelbetrieb kanndie Leistung auf 2 MW erweitert werden

 Mit derHochfrequenz-Schaltweise unterstützt das Gerät das automatische Umschaltenzwischen Konstantspannung (CV) und Konstantstrom (CC)

 Wirkungsgrad der Stromversorgung vonbis zu 95%

 ZahlreicheSchutzfunktionen (OVP, OCP, OPP, OTP, Schutz gegen Stromausfall sowie Schutzgegen Unterspannung am Eingang)

 UnterstütztDatenaufzeichnung; kontinuierliche Aufzeichnung von Parametern wie z.B.Maximal-, Minimal- bzw. Mittelwert von Ausgangsspannung bzw. Ausgangsstrom; dieAufzeichnung kann nach definierter Reihenfolge automatisch erfolgen

Unterstützt externe Datenaufzeichnung und interne Datenpufferung; ein PCkann regelmäßig aus dem Gerät Messdaten abrufen

USB/CAN/LAN/digitale E/A-Kommunikationsschnittstelle als standardmäßigeAusstattung sowie GPIB/Analogschnittstelle & RS232-Steuerschnittstelleoptional erhältlich

 Unterstützt dasSCPI-Protokoll, integrierter Web-Server








Funktionen und Vorteile

3U/18kW

Die Baureihe IT6000D verfügt über hoheLeistungsdichte von 18 kW bei 3U und zeichnet sich mit reduzierterGeräuschbildung bzw. Welligkeit am Ausgang, hervorragender Anpassungsfähigkeitgegen Störspannung, hervorragender Lastregelung sowie Schnelligkeit beiKurzzeitreaktion aus. Die Baureihe besitzt einen großen Spannungsbereich von 80V bis 2250 V sowie einen großen Strombereich von 510 A bis 30 A und eignet sichals Stromversorgung für jegliche Prüfaufgaben von der Produktentwicklung überProduktion bis hin zur Produktprüfung.





Ausgangseigenschaften


Im Vergleich zur traditionellen Gleichstromversorgungmit festen Ausgabewerten ist die Baureihe IT6000D, innerhalb desLeistungsbereichs unterschiedliche Kombination aus Spannung und Strom zuverwirklichen und gleichzeitig mit voller Leistung zu arbeiten. Eine einzelneStromversorgung dieser Baureihe ist schon in der Lage, Anwendungen, die nur mit3 bis 5 traditionellen Stromversorungen realiserbar sind, zustand zu bringen.Drei Stomversorgungen dieser Baureihe ensprechen dann der Funktionalität von 10bis 13 traditionellen Stromversorungen. Somit wird die Komplexität beimAufstellen der Stromversorgung sowie der Platzbedarf erheblich reduziert.



Database
Related Products
Relevant Solutions
***Item is required. Please submit the information after completion.
You have submitted it successfully, We will review it as soon as possible.

No Records

Mehr Product / Solutions
